Furniture D5S Linear ATC CNC Router with Suspension feeding Table
High-efficiency D5S Linear ATC CNC Router with suspension feeding system, specially built for scratch-free processing of high-gloss PET and coated panels. Features 13002800200mm working area, 9KW air-cooled spindle, Taiwan LNC control, and auto loading/unloading to maximize workshop productivity.
Model:CX-D5S,CX-1325,CX-1328
Send Inquiry
Product Description
Feature of CNC Nesting Machine:
- Precision Frame & Structure: Engineered with a specialized quenching and tempering process to ensure maximum frame strength, long-term durability, and zero structural deformation.
- Integrated Heavy-Duty Design: Built with an integrated through-type rack structure that guarantees top-tier equipment processing accuracy and rigidity.
- In-House Manufacturing Excellence: Fully independent production lifecycle—from riveting, annealing, shot blasting, and precision machining to sheet metal fabrication, assembly, and direct after-sales service.
- Automated Smart Loading System: Effortlessly integrates with automatic loading and unloading production lines to minimize manual labor and maximize workshop efficiency.
- Zero-Scratch Suspended Feeding: Features a suspended feeding mechanism designed specifically for delicate materials (PET high-gloss boards, paint-coated panels, and decorative sheets), ensuring zero surface scratches and flawless edge protection.Machine Parameters:
Machine Parameters:
Model
D5S
Work Size
1300*2800*200mm
Cutting spindle
JST 9KW Air cooled
Servo drive system
Servo motor
control system
Tai wan LNC+ Remote control
deceleration mechanism
Shimp reducer
Rack and pinion
1.5M
Guide rail screw
X/Z 25#， Y 30#
Positioning Method
3+4 high-precision automatic positioning cylinder button type one key positioning device one key starting device
Bed structure
High precision heavy-duty side hanging bed body, processed by a large CNC five sided milling center
Table structure
Vacuum adsorption table, multi-point adsorption/multi slot design/uniform adsorption/instant adsorption/instant release
Electrical accessories
Schneider of France/Omron of Germany/CHINT of China
Frequency converter
11KW/380V
Vacuum Pump
7.5KW water pump
Dust collector
5.5KW, floating vacuum cleaner+central dust collection structure+dust-free vacuum hood
Gantry
Five sided gantry milling precision machining center
Quality control
assembly, testing, and delivery, with 72 hour research and testing
Application:
Custom Furniture & Cabinetry: Panel furniture, kitchen cabinets, wardrobes, bathroom vanities, door panels, and custom interior fit-outs.
High-Gloss & Delicate Panel Processing: Specialized scratch-free cutting and drilling for high-gloss PET door panels, painted sheets, and seamless edge-banded doors.
Interior Decoration & Wall Panels: Decorative wall cladding, wooden screens, acoustic panels, and baseboards for soft/hard upholstery.
