Six Side Drilling Machine
The Six Side Drilling Machine has the functions of drilling, slotting, rounting and milling. The frame is precisely machined by CNC gantry machining center. The original authentic HQDKW air-cooled spindle is used, which has the function of dust collection. The heavy-duty bed adopts integrated welding, annealing and aging treatment.
Send Inquiry
Product Description
Six Side Drilling Machine Feature：
The machine frame is precisely processed by the CNC gantry machining center.
Frame structure: heavy bed, precision welding, laser cutting, frame bed, high temperature tempering, aging treatment, enhance rigidity, and ensure the stability of the bed.
Six side machining: without shunting, one equipment can realize the machining of six faces and the slotting of the front and back faces.
Double drill bag: 2+1 drill bag mode is adopted to improve efficiency by 30%.
Drilling workstation: multiple drilling center workstations can be formed to realize streamlined operation.
Frame structure: heavy bed, precision welding, laser cutting, frame bed, high temperature tempering, aging treatment, enhance rigidity, and ensure the stability of the bed.
Six side machining: without shunting, one equipment can realize the machining of six faces and the slotting of the front and back faces.
Double drill bag: 2+1 drill bag mode is adopted to improve efficiency by 30%.
Drilling workstation: multiple drilling center workstations can be formed to realize streamlined operation.
Specification:
| Items |
CX-612A single drilling bag |
CX-612B double drilling bags |
||
| Working area | Length of X axis grip guide rail | 5400mm | ||
| Travel Y-axis | 1200mm | |||
| Z-axis stroke | 150mm | |||
| Max Speed | X axis | 54000/min | ||
| Y axis | 54000/min | |||
| Z-axis | 15000/min | |||
| Working size | Min size (L * W) | 200*50mm | ||
| Max size (L * W) | 2800*1200mm | |||
| Number of tools | Up drilling | 9 vertical drills | 9 vertical drills*2 | |
| Below drilling | 6 vertical drills | |||
| Up drilling(XY direction) | 4 horizontal drills | 4 horizontal drills*2 | ||
| Frequency converter | Inovance 380V4KW 2台 | |||
| principal axis | HQD 380V 4KW 2台 | |||
| Work-piece thickness | 12-30mm | |||
| Overall dimensions of the machine | 5400*2750*2200mm | |||
| Drill bag brand | Taiwan | |||
| Control system | Taiwan LNC | |||
| Servo drive motor | Inovance Servo motor | |||
| CAM software | Higerman | |||
| Guide | X axis | Taiwan ANDE | ||
| Y axis | Taiwan ANDE | |||
| Z-axis | Taiwan ANDE | |||
| Rack | German grinding ruler | |||
| Ball screw | Taiwan ANDE | |||
| Reducer | SHIMPO | |||
Applicable industry:
Mainly used in the production of panel furniture industry, mainly used for six sides (hinge holes, through holes, half through holes) and horizontal broaching of various wood-based panels.
